Washing machines and associated problems with sizes

washing machines with different sizes

Finding a smaller, or slimmer washing machine is very difficult. If you need one that’s just a millimetre or so smaller, you may be able to find one. But if you require one much smaller than that, you may find it impossible. This article gives explanations, tips, and workarounds that may help.


Is there a standard washing machine size?

There isn’t a standard size, but there is a standard kitchen space for them to fit into, which is 60 cm wide, 60 cm deep and at least 85 cm high. Therefore, the vast majority of washing machines are around this size, and differ from these measurements by only a millimetre or so – especially height and width.

Most washing machines are 85 cm high, between 59 and 60 cm wide, but vary more in depth (explained later).

Washing machine sizes vary – but not by much

It’s important to realise that washing machine manufacturers need their washing machines to be as large as possible, especially in order to accommodate modern extra-large drum capacities.

Making a washing machine smaller than normal will compromise the ability to fit everything inside. There’s nothing in it for them to make one several mm less wide, or tall.


Can you buy a slimline washing machine?

Over the years, there have been several “slimline” washing machines that were quite a lot smaller. Some were about 15 cm less wide. But they had much smaller drum capacities, and not suited for families at all. Some were only 3Kg drums.

These extra slim or compact washing machines also presumably never sell in enough quantities to make them viable, as they tend to get discontinued after a few years.

If you are desperate, you can try searching online for “slimline washing machine” or “compact washing machine”. However, although you will get results, you may find it frustrating that these don’t lead to what you are looking for.

The majority that I can currently find are only slimmer in depth, and not in width. If this is what you need then that’s fine, but it is width that causes most people problems. The depth only dictates how far a washing machine sticks out. Be sure to look at the drum capacity and double check the dimensions of anything that comes up.


Washing Machine width

Width

The most common size problem seems to washing machine width, where a washing machine is too wide to fit into the space under a kitchen worktop. In the UK we have many small kitchens. So compromises are often made on the space.

There are very few washers with much smaller widths than other brands. Top loading washing machines, or rare compact washing machines with very small drums, will be significantly less wide. But they are unsuitable for most people. Plus, a top loader can’t have a worktop above it.

In my random check of 33 examples of different washing machine sizes and dimensions 32 were between 59 and 60 cm wide. Only one was less wide at 52 cm. However, I didn’t double-check if it was a mistake or not.


Quoted measurements can be wrong. If you find one significantly different – make sure it isn’t a mistake. Check with the manufacturer.

If such a mistake came from the manufacturer, it will be wrong everywhere.

Note that there may be other washing machines with smaller widths that I didn’t come across.

You need to remember that it’s unlikely you will find a normal washing machine that is several millimetres less wide. If desperate, you will need to search online.

Minimum 2 Year Guarantee on Appliances
Appliances at John Lewis

Washing machine height

Height

Washing machine height is the same on virtually all washing machines. Out of the 33 washing machines I checked, only 3 were less than 85 cm high, and that was only by 1 mm.

However, there is a potential workaround to this…

Lowering a washing machine height

Many manufacturers make what’s called a height reduction kit. This involves removing the lid and replacing it with a very thin, flat one. This alone can reduce the height of a washing machine by 20 mm or so.

This is usually more than enough to let it fit under a lower than normal kitchen worktop. It also typically involves removing the feet, and fitting smaller studs. However, you shouldn’t just remove the lid yourself. There are some safety issues to bear in mind, as discussed in my reducing height of washing machine article.


Washing machine depth

Slim washing machine

There is more variation in depth than any other dimension. Sometimes several millimetres. But ironically, this is often the least critical measurement. A washing machine that’s deeper than average can usually still fit in the space. It will just stick out a bit more, and this is not always a problem.

The following photo shows how a washing machine may be a bit too deep, but it rarely prevents one from being fitted.

Washing machine sticks out

Beware of washing machine depth

There are some potential pitfalls to having a washing machine that is too deep. Watch out for the depth of a washing machine if you have kitchen drawers, cupboard doors, or even main doors opening across it.

You must take into account how modern washing machines (and matching tumble dryers) have a tendency to bulge out at the front, or have large doors that stick out quite a way.

I recently installed a new washing machine for my daughter, and was reminded about this issue.

After installing the washing machine in my daughter’s kitchen, my heart sank as I realised that their back door, which opens across it, was going to catch on the washing machine.

I managed to push it back far enough for the door to just clear – the following photo highlights this issue extremely well…


Door sticks out
Beware of depth if drawers or doors open across it

Tips for finding smaller washing machine

Comparison sites usually let you filter results by height, width, and depth. So use them, but do not explicitly trust the measurements quoted on websites. If a web site says a washing machine is the smaller size you are looking for – double-check the stats on the specifications page. Check it on multiple websites.

If mission-critical, and it seems a lot different to the rest, then check with the manufacturer. Bookmark or copy the page. Print it out. You can use this as evidence if it turns up and is bigger than the specifications said, so you can reject it. I’ve seen several cases where quoted measurements were wrong!


If you do find a washing machine smaller than standard dimensions and the size requirement is critical, make sure you double-check what drum capacity it is. Reduced dimensions often means reduced drum size. Some might be the size you need but have very small drum capacities (eg 3.5 Kg)


Always check out the measurements of a new appliance when replacing an old one. Even if you currently have a washing machine in there that fits. There could be small but critical differences, and modern washing machines are often wider and deeper than ever.

Dimensions are usually available in the “specs”, product info, or “specifications” section describing the appliance being sold, either in the brochure or on a web page.

The depth of a washing machine quoted by the manufacturer should in theory take into account the whole depth, but does it include the way the front may bulge out as well as the door? If critical, double check.

More on washing machine depth

If a washing machine measurement states that it is 60 cm deep, does this mean that all the piping and electrical wiring at the back will fit under a worktop of 60 cm depth? — do washing machine depth specifications include pipes & hoses?


Washing machine sizes comparison

I’ve published a table of different washing machine measurements (not models or brands) that I found when checking 33 random washing machines.

Anyone looking for a smaller than normal washing machine should find it useful to at least see how the average washing machine varies in size – or not. Check out the 33 examples of washing machine sizes and dimensions.

Forbes Rentals

Forbes specialise in renting Bosch appliances so they know them inside out. They also rent other brands and many other products.

  • No initial financial outlay
  • Prices start at around £3.91 per week
  • No more repair bills
  • Fast repair service same day/next day
  • Stop constantly having to buy new ones
Repairs
Fixed-price repairs, Pay monthly, Repair & protect your whole appliance..
50% off annual membership

Subscribe to Which? today and save 30% on Digital Annual subscription for your first year. Offer ends 18.03.24. This offer is only available for new Which? annual subscriptions (excluding Gardening, Travel, Computing or Money packages).

Various membership options available.
Spares

Ransom Spares is a family company with over 1 million spare parts. Next day delivery available, friendly company with over 5000 reviews on Trust Pilot - Buy your appliance spare part

Price match promise: "If you find the exact same part cheaper, we’ll not only match it, we’ll beat it!"

Comments need to be on topic with the article (Moderated before appearing).

57 thoughts on “Washing machines and associated problems with sizes”

  1. Hitendra Varsani

    Hi

    I have been searching for a freestanding washing machine ideally about 82cm/83cm in height. For my old washing machine I ended up having to take the nuts off the legs to get it to fit into its space (under a worktop) after a kitchen refurb. I cannot seem to find any. I called a few washing machine manufacturers and they all said they dont have height redunction kits anymore due to the location of their washing machine electronics. My current washing machine is about to pack up so I need a replacement. Any ideas?. I thought about buying a integrated one(although it wont look great)

    Thanks

  2. margaret macdonald

    Could you please tell me if there are any machines I can fit in space and put a cabinet door over it, I already have this but unfortunately after 13 years my machine isn’t working now and the model is discontinued. Not having a utility room this worked perfectly so am looking for a small depth machine.

    1. Andy Trigg (Whitegoodshelp)

      Hello Margaret. I’m pretty sure you would have to have a built-in washing machine to achieve that.

  3. Gillian Goodchild

    Am trying to find a washing machine which will fit into a space 84cm x 55cm. Not so bothered about depth (Why on earth would a kitchen refurbishment in a local authority flat not have standard sizes??) Any pointers?

    1. Andy Trigg (Whitegoodshelp)

      Hello Gillian. Yes it’s very frustrating. There is very little excuse that I can think of unless a kitchen is designed specifically for someone who has requested lower worktops. Washing machines are usually 85 cm high, so making a worktop just 1 cm lower is ludicrous and can not possibly have any benefit. Widthwise, they should be 60 cm, so saving 5 cm may be useful in a small kitchen but only if it is absolutely necessary because again, washing machines are not made at 55 cm wide, they are on average 59 cm wide.

      If your kitchen is extremely small it’s possible there wasn’t much choice, although as I said saving 1 cm in high seems pretty pointless. Widthwise is a different matter, though. In an extremely small kitchen it may be difficult, but anybody in the kitchen fitting business should know that if you do not create spaces which are the standard 60 x 60 cm, then you will definitely not be able to fit the overwhelming majority of either washing machines or dishwashers in there.

  4. Hi
    I have recently taken out an integrated washer/drier of 52.5cm max depth (inc . door etc.). Unfortunately I cant find a replacement one that fits , can you help please
    Regards
    Michael Clarke

    1. Andy Trigg (Whitegoodshelp)

      Sorry Michael. The only thing you can do is trawl through all the sites selling them, and look at the specs of them all to try and find one. If you’ve already done that and can’t find one, they probably don’t make one. If that’s the case and it’s depth you need you would have to try a kitchen company for ideas. It’s crazy that people have this problem.

  5. David Williams

    Trying to replace a Siemens 7kg machine but the spacedimensions available are 59.5cm width, 84 cm height and a limiting 58cm depth, any ideas if machines that could fit. The Siemens model we’ve had for 13 years is now discontinued

    1. Andy Trigg (Whitegoodshelp)

      Hello David. I think the conclusion of my article and research was that when it comes to height and width, there aren’t any smaller washing machines other than the odd millimetre. Not having enough depth is the least problematic size issue unless you have a door or drawer that opens across the washing machine like the one in my article. It’s also the measurement that has the greatest size differences when I did my research (Washing Machine Sizes Comparison) though I can’t sure whether these were real differences and not for example differences in the way manufacturers measure.

      For example, could one measure the literal depth of the cabinet and another measure the depth of the lid which overhangs at the back? The only thing you can do is to scour price comparison sites or manufacturers sites and study the technical specifications where size is always quoted.

  6. wendy Dennison

    I’m having the same problem as the ones already mentioned. I need a machine to fit a space h- 86cm w-63cm and d-60cm. I’ve spent hours looking on line and the only one I can find is a tiny compact Zanussi which is not fit for purpose and doesn’t have great reviews. I’ve read that machines need at least an inch of space at the sides and top and several at the back to allow for pipe work? my current Indesit machine is on its way out after 10 years of brilliant service. Any advice would be gratefully received!!

    Wendy.

  7. Linda Gerring

    My old Bosch machine is 59.5 cm wide and there is no room at all either side. I had a new kitchen installed 11 years ago and I noticed they could barely fit the washer in then (it was already 11 years old then). Now it leaks so I can’t use it but cannot find any machines to replace it. I would never buy possible dangerous ones and want a good make. Have spent days trawling Internet but the nearest is a Miele 59.6cm. At the moment I can’t put a feather between fitted cupboards either side. I feel very stressed as Car not working, kitchen wall needs decorating after new central heating installed. What do other people do in such situations?

    1. Andy Trigg (Whitegoodshelp)

      Hi Linda. It’s very frustrating when they don’t leave the full 60 cm space. When I did some research for this article I found several washing machines at 59.5 and even 59 mm. I used a price comparison site and filtered by width.

  8. I live in a block of flats specifically designed for use of wheel chair users and therefore the height of the units is lowered. The height of a washing machine needs to be 80-82 centimetres. Machines of this height appear to be very difficult to find. Surely there is a market for smaller machines to conform with the needs of the disabled under the Disability Act?

    1. Andy Trigg (Whitegoodshelp)

      Hello Mary. The only thing I can think of is built in washing machines, which are much lower than a freestanding washing machine. They are normally raised up by up to 5 or 6 inches using plastic windup legs and feet. I would imagine that in the situation that you describe, one would be fitted into the kitchen and not raised up to the standard height.
